CS-4 TABLET FRIABILITY TESTER
CS series of instruments are used for detecting friability/ abrasion of tablet.
Applicable standards:
National standard (Chinese codex) /2010
Corporate standard (Dissolution tester) Q/12XQ0189-2010
Features:
Two drums run synchronously. Auto stop at timing point.
The drum is made of high quality hyaline acryl.
The speed and revolution of the drum is constant, either preset or real data is displayed on the LED.
A MPU is used to control all operations, high accuracy is achieved in testing rotary speed and circle number.
Automation: auto-test, auto-diagnose, auto-alarm.
Cylinder number 1
Cylinder radius Φ286mm
Cylinder depth 39mm
Tablet fall height 156mm
Rotation speed 25rpm
Rotation Speed accuracy ±1rpm
Rotation count 100r
Rotation count accuracy ±1r
Power 220V/ 50Hz/ 50W or 110V/ 60Hz/ 50W
Dimension (370×200×340)mm
Weight 6kg
