ND-1 BLOOM VISCOSITY TESTER
ND series of instruments are used for detecting bloom viscosity of gelatin.
Applicable standard
National standard (Food additive Gelatin) GB6783-94
Vocation standard (Gelatin for medicine) QB2354-98
Corporate standard (Thickness tester) Q/12XQ0193-2010
Features:
A MPU is used to control all operations in Bloom Viscosity tester. It works in Bloom mode and the viscosity data is displayed by LED.
High temperature accuracy. Even temperature of the bath liquid.
Using capillary and precise photo-electricity transducer.
Automatically calculating time and viscosity.
Auto-timing, auto-alarming, auto-testing continually.
Auto-preset piece number, auto-test hardness, display preset and real-time data alternately in time.
Automation: auto-test, auto-diagnose, auto-alarm.
Test range (0～9.99) mPa·s
Test accuracy 0.05mPa·s
Temperature control 60.0℃
Temperature control accuracy ±0.1℃
Volume 100ml
Volume accuracy ±0.5ml
Recital distance (152±2)mm
Power 220V/ 50Hz/ 600W
Dimension (400×300×510)mm3
Weight 12kg
