Application:
This machine is double side rotary tablet press machine, which can press granular materials into round shape tablet and irregular tablet, it is mainly used in pharmaceutical, chemistry, foodstuff, electronic industries.
Feature:
1. Double press type with mass production capability.
2. Made of stainless steel, the housing is fully closed. The surface of the rotary turret is covered with a hardened layer so that the turret surface is wear resistant. The machine conforms to GMP requirements.
3. Adopt transparent windows, tableting state can be observed clearly. The windows can be opened, cleaning and maintenance is easy.
4. Hydraulic overload protection device is equipped, the machine can stop automatically in case of overpressure to protect the punch pins from being damaged.
5. Separate the control cabinet from main machine, ensure the sanitation from production.
6. Force feeder is optional on the machine.
7. The machine can support to make double layer tablets after some changes (optional).
Model | ZP41A | ZP45A | |
Numbers of Punch Stations | 41 | 45 | |
Punch Type | ZP | ZP | |
Max Pressure (kN) | 80 | ||
Max Tablet Diameter (mm) | round tablet | 20 | 13 |
irregular tablet | 22 | 16 | |
Max Filling Depth (mm) | 15 | ||
Max Thickness of Tablet (mm) | 6 | ||
Max Turret Rotation Speed(r/min) | 45 | ||
Max Production Capacity (tablets/hour) | 221400 | 24300 | |
Motor Power (kw) | 4 | ||
Dimensions (mm) | 1120×980×1720 | ||
Weight (kg) | 2000 | ||
