DPH220 260 High Speed Blister Packing Machine
Application:
It is the latest roller and plate type blister packing machine at high precise, developed by our company. It applies to pharmaceutical industry, food industry, medical appliance and electronic area. It is suitable for packing capsules, tablets, softgel, candy, electronic element and similar material with blister packing in AL/PVC and Paper/PVC.
|
Model
|
DPH-220
|
DPH-260
|
|
PVC Pharmacy PVC
|
(0.2-0.4)*220mm
|
(0.2-0.4)*260mm
|
|
Aluminum Foil PTP
|
(0.02-0.05)*220mm
|
(0.02-0.05)*260mm
|
|
PVC&PTP
|
Diameter of Outer Reel <Φ400m
|
|
|
Diameter of Reel Core <Φ70-80m
|
||
|
Packing Speed
|
40-120 Times/min
|
40-120 Times/min
|
|
Packing Efficiency
|
Capsule:110,000-170,000 pcs/h
|
Capsule: 160,000-260,000 pcs/h
|
|
Tablet: 150,000-300,000 pcs/h
|
Tablet: 220,000-450,000 pcs/h
|
|
|
Compressed air (pressure)
|
0.6-0.8MPa
|
0.6-0.8MPa
|
|
Air consumption (m3/min)
|
≥0.4
|
≥0.4
|
|
Overall Dimensions (L*W*H)
|
3140*940*1600mm
|
3140*940*1600mm
|
|
Weight
|
2500kg
|
2800kg
|
|
Install Power
|
12.5Kw 380V 50Hz
|
|
